The 4-power RAPTOR« night vision weapon sight incorporates advanced performance and GEN 3 image tube technology. Rugged yet lightweight, the RAPTOR is the most accurate night imaging device designed for long-range accuracy. The RAPTOR can be mounted on almost any weapon with a MIL-STD-1913 rail or STANAG, and withstands the shock of full automatic fire of weapons such as the M4/M16/AR15/M249 and most other shoulder fired small arms. This weapon sight incorporates a red duplex reticle with variable brightness control, and can be zeroed with separate windage and elevation adjustments. The RAPTOR is the best weapon mounted dedicated NV (night vision) 4X (power) weapons scope available anywhere.

Military:
The 4X Raptor is an ideal NV weaponsight to improve accuracy for targeting and shooting and increase the success of the overall mission. Designed to meet military requirements, the 4X Raptor offers the individual soldier an advantage over the enemy.

Law Enforcement:
The 4X Raptor is the ultimate NV targeting tool for any tactical officer or agent. With its accuracy and long distance range, the 4X Raptor is perfect for use in tactical operations at night.

Security:
Armed security personnel can utilize the NV 4X Raptor, mounted on almost any weapon to enhance shooting and targeting ability when securing a perimeter or facility.

Specifications:
Physical Characteristics
Size (inches) 12 x 3.75 x 3.5
Weight 3 pounds, 6 ounces (includes mount)
Mounting Provisions ARMS #11 & 19A mounts

Operating Characteristics
Tube Type
ITT MX-10160, Gen 3 Intensifier Tube
Tube Resolution: 64-72 lpmm
Tube SNR 20 N/A
Tube Spectral Range 450-900 nm
Tube Life 10,000 hours (typical)
FOV 8.3?, circular
Diopter Adjustment -6 to +2 diopters
Eye Relief 30 mm, minimum
Reticle Color/Type Red / Duplex
Reticle Adjustment ▒ 17 mils
Obj. Lens (EFL) 125 mm
Objective Lens f/no. f/1.7
Focus Range 25 meters to infinity
Magnification 4X
Detection Range(man sized target) 1857 m (╝ moon)
Operating Time 55 hours at 72? F (AA Alkaline)
ITT MX-10160, Gen 3 Intensifier Tube
Tube Resolution 64+ lp/mm FOM 1250 FOM 1600
Tube SNR 20 N/A
Tube Spectral Range 450-900 nm
Tube Life 10,000 hours (typical)
FOV 8.3?, circular
Diopter Adjustment -6 to +2 diopters
Eye Relief 30 mm, minimum
Reticle Color/Type Red / Duplex
Reticle Adjustment ▒ 17 mils
Obj. Lens (EFL) 125 mm
Objective Lens f/no. f/1.7
Focus Range 25 meters to infinity
Magnification 4X
Detection Range(man sized target) 1857 m (╝ moon)
Operating Time 55 hours at 72? F (AA Alkaline)

Electrical Characteristics:
Power Source
2 AA batteries or BA-3058/U (alkaline or lithium) or BB-5567/U (lithium)

Environmental Characteristics:
Operating Temperature
-60? F to +113? F
Storage Temperature -60? F to +160? F

Environmental Characteristics:
Operating Temperature
-60? F to +113? F
Storage Temperature -60? F to +160? F
COMPLETE WITH ARMS THROW LEVER MOUNT, BATTERIES, MANUAL, NYLON ZIPPER CASE AND WATERPROOF PADDED STEEL USGI OPTICS TRANSIT CASE
